Tennant 3640 Walk-Behind Floor Sweeper
Tennant 3640 Walk-Behind Floor Sweeper
Description
The Tennant 3640 Walk-Behind Sweeper is a durable and dependable sweeper that can clean floors in tough environments. This industrial floor sweeper offers dual side brushes for maximum cleaning and provides you with tool-free features to help make servicing easy. When you have a vacuum wand and the optional timed shaker for the panel filter, picking up dirt and debris is made simple. The Tennant 3640 Walk-Behind Floor Sweeper is a durable and dependable mid-sized sweeper with optional attachments to maximize productivity. Sweep almost any environment, inside or outside, and pick up anything from sand to larger debri or trash. The HEPA panel filter optional attachment is available to maximize dust control; creating better air quality and has an optional timed shaker. Tool-free maintanance helps boost productivity and makes changing brushes and batteries easier. Increase your run-time with the extended battery to make the most out of shifts. The larger designed hopper is capable of picking up 1.5 cubic feet of sand and 3 cubic feet of trash/debris. This machine comes with many optional attachments and tools. If you need a reliable sweeper, the Tennant 3640 may just be what you’re looking for. Similar Products: Tennant S9 Walk-Behind Sweeper, Tennant S10 Walk-Behind Sweeper Tennant 3640 Walk-Behind Floor Sweeper Documentation
Specifications
Manufacturer | Tennant |
Condition | New |
Cleaning path, single side brush | 62.5 in. |
Cleaning path, dual side brush | 80 in. |
Average (4 mph) | 133,760 sq.ft. |
Maximum (8 mph) | 281,600 sq.ft. |
Main brush length | 45 in. |
Main brush lift | Mechanical or Hydraulic |
Main brush change | No-tool |
Side broom diameter (disk) | 26 in. |
Hopper volume capacity | 14 cu.ft. |
Hopper weight capacity (plastic) | 1,080 lb. |
Hopper weight capacity (steel) | 1,200 lb. |
Hopper dump height (variable) | 60 in. |
Hopper dump reach | 30 in. |
3- wheel (gas/lp) | 14 deg. |
X4 (diesel only) | 9 deg. |
Propel type | Hydrostatic |
Ground clearance | 4 in. |
Tires front (2), solid | 5 x 21 in. |
Tire rear (1), pneumatic | 4.5 x 18.5 in. |
Tire rear (2), foam-filled (x4) | 4.5 x 15.5 in. |
Gas/lp | 50 hp |
Diesel | 24.8 hp |
Hydraulic pumps | 1 propelling, 3 accessory |
Stage 1 | Perma-Filter™ |
Stage 2 | SweepMax® Plus Cyclonic Pre-Filter |
Stage 3 | Donaldson Ultra-Web® Nanofiber Canister Filter |
Filter area | 80 sq.ft. |
Dust filtration | .5 microns @ 99% efficiency |
Shaker mechanism | ShakeMax® 360 Orbital Shaker |
Vacuum fan diameter | 11 in. |
Normal sweeping mode | 4,600 rpm |
Litter sweeping mode | 5,500 rpm |
Length | 93 in. |
Width | 62.5 in. |
Height without overhead guard | 58 in. |
Height with overhead guard | 82.5 in. |
Net (3-wheel) | 3,570 lb |
Turning radius | 65 in. |
Minimum aisle turn (left) | 113 in. |
Fire protection | Thermo-Sentry™ |
Safety certification | UL label type G, LP, D |
Forward speed when dumping | 1.0 mph |
Headlights/taillights | Standard |
Power steering | Adjustable foot pedal |
System monitoring/ warning lights | Tilt steering w/ horn |
High-back seat | Touch panel controls |
